Operating Conditions

MTU brush seals can be used under the most varied of operating conditions and fully meet the stringent requirements imposed on advanced sealing systems. MTU brush seals can be used for static and dynamic applications alike. They are suitable for operation in a variety of fluids and are capable of withstanding high operating loads.

Operating conditions for MTU brush seals

Application:static / dynamic
Operating media:gas / fluids
Max. differential pressure per sealing element:up to 2,000 kPa
Max. differential pressure of several sealing elements installed one behind the other:up to 6,500 kPa
Temperature:up to 700 degrees Celsius
Sliding speed:up to 500 m/s
Relative radial movement:up to 4 mm
Relative axial movement:unlimited
